Flourish Software's

Direct Thermal Cannabis Labeling Guide

Placeholder text

For Cannabis Operators Using ZD421 or ZT411 Printers



This guide helps you choose the right direct thermal labels for packaging, shipping, and compliance. Whether you're labeling pre-rolls, flower bags, or shipping boxes, this reference ensures you're using the correct sizes and materials no ribbon required.

Use Direct Thermal if you need quick, low-cost labels for products that move fast and don’t require rugged durability.



Flourish Equipment Store

Shop labels, printers, and gear in our hardware store

What is Direct Thermal?

Direct thermal labels use heat to print no ribbon needed. They’re ideal for short-term use (under 1 year) and are fast, clean, and easy to reload in the field.

Best for:

  • Pre-roll tubes & jars

  • Flower & concentrate bags

  • Retail packaging

  • Shipping boxes

Recommended Standard Label Sizes (ZD421 Compatible)

Use Case Label Size (mm / in) SKU Notes
Pre-rolls / Jars 40 × 15 mm (1.57 × 0.59 in) LD4015-2.5B Compact; great for small round surfaces
3.5g Bags 69 × 48 mm (2.72 × 1.89 in) LD6948-6A Mid-size; fits branding + compliance
Shipping Boxes 102 × 152 mm (4 × 6 in) 3010066-T Industry-standard shipping label

 All fit ZD421 print width (≤ 104 mm) and standard 25 mm cores.

Genuine Zebra Direct Thermal Labels (ZD421-Compatible)

Economy Paper (Z-Perform 1000D)

  • 3010066-T – 102 × 159 mm (~1,064/roll)

  • 880191-076D – 102 × 76 mm (~1,997/roll)

    10026372_1__13839

Premium Top-Coated Paper (Z-Select 2000D)

  • 87000 – 100 × 50 mm (~14,650/box)

  • 800261-105 – 32 × 25 mm (check vendor listing for label count)

    z-select-2000d-spec-sheet-asset-photography.jpg.imgw_.1920.1920

Sample Labels from Barcodes Group

SKU Size (mm) Labels/Roll Rolls/Box Adhesive
LD4015‑2.5B 40×15 2,500 1 Permanent
LD4028‑10A 40×28 2,000 5 Permanent
LD4028‑10R 40×28 2,000 5 Removable
LD6948‑6A 69×48 1,000 6 Permanent
LD10235‑8A 102×35 1,000 8 Permanent
LD10274‑0.5RA 102×74 500 1 Removable

ZD421 supports 25 mm or 38 mm cores, up to 104 mm wide.

Choosing the Right Label

 Size
Make sure width is ≤ 104 mm (ZD421) or ≤ 114 mm (ZT411).

 Adhesive

  • Permanent for packaging, product labels, and shipping

  • Removable for returnable bins or temporary use

 Material

  • Z-Perform 1000D: Affordable economy label

  • Z-Select 2000D: Premium, coated for barcode durability

 Core & Roll Compatibility

  • ZD421: 25 mm core, 5” outer diameter

  • ZT411: 76 mm (3") core, up to 8” OD

ZT411-Specific Direct Thermal Labels

Supports wider and larger rolls for higher throughput.

Use Case Label Size (mm / in) SKU Core / OD Labels / Roll
Pre-rolls / Jars 40 × 15 mm (1.6 × 0.6 in) LD4015‑DT3P 3″ / 8″ ~2,500
3.5g Bags 69 × 48 mm (2.7 × 1.9 in) LD6948‑DT3P 3″ / 8″ ~1,000
Shipping Boxes 102 × 152 mm (4 × 6 in) DT400650‑3P 3″ / 8″ ~3,600

Also compatible: 3010066-T (Z-Perform 1000D) and Z-Select 2000D equivalents.

Setup Tips

No Ribbon Needed – Use direct thermal mode only

  • Sensors – Set to gap or black mark detection depending on label type

  • Label Storage – Keep in a cool, dry place to preserve adhesive and print quality

  • Calibration – Always calibrate when switching label sizes or types

  • Use Certified Labels – Prevent premature printhead wear by using Zebra-compatible stock
